HT-13Q Hydraulic Pilot Mini Excavator: Compact, Strong and Easy to Transport
The HONGTAI HT-13Q hydraulic pilot mini excavator brings full-size control feel to a 1,000 kg machine. A load-sensing distribution valve, variable-displacement piston pump and hydraulic pilot joysticks give smooth, proportional control, while the Kepu 195 diesel engine provides dependable power for all-day digging.
Every HT-13Q is built and tested in our factory and supplied direct to equipment dealers, rental companies, landscapers and contractors worldwide, with OEM branding available.
Key Features
- Hydraulic pilot operation for smooth, low-effort joystick control
- Load-sensing distribution valve and variable-displacement piston pump for efficient multi-function work
- Kepu 195 diesel engine, 8.6 kW at 3,000 rpm
- 40° climbing ability on rubber tracks
- Mounted safety lock to prevent accidental operation when entering or leaving the seat
- NOK-sealed cylinders and hoses and wear-resistant rubber tracks
Technical Specifications
| Parameter | Metric | Imperial |
|---|---|---|
| Weight | ||
| Operating Weight | 1,000 kg | 2,205 lbs |
| Dimensions | ||
| Transport Length | 2,967 mm | 116.8 in |
| Transport Width | 1,050 mm | 41.3 in |
| Transport Height | 2,290 mm | 90.2 in |
| Working Range | ||
| Max. Digging Radius | 3,063 mm | 10.0 ft |
| Max. Digging Depth | 1,700 mm | 5.6 ft |
| Max. Digging Height | 2,700 mm | 8.9 ft |
| Max. Dumping Height | 1,855 mm | 6.1 ft |
| Max. Digging Force | 9 kN | 2,023 lbf |
| Engine & Travel | ||
| Engine | Kepu 195 diesel | |
| Max. Power | 8.6 kW @ 3,000 rpm | 11.5 HP @ 3,000 rpm |
| Travel Speed | 0 – 1.8 km/h | 0 – 1.1 mph |
| Climbing Angle | 40° | 40° (84% grade) |
| Options | ||
| Optional Attachments | Hydraulic breaker (hammer), ripper, log grapple, rake, auger drill, large bucket, mud (ditching) bucket | |
| Track Option | Steel tracks available | |
Specifications are taken from our factory brochure and may vary with configuration. Contact us for the latest datasheet.
Standard Configuration
Kepu 195 diesel engine, load-sensing distribution valve, variable-displacement piston pump, hydraulic pilot operation, hoses with NOK seals, adjustable dozer blade, wear-resistant rubber tracks, adjustable seat, standard bucket, canopy, mounted safety lock.
Optional Attachments
Hydraulic breaker (hammer), ripper, log grapple, rake, auger drill, large bucket, mud (ditching) bucket. Attachments can be supplied with the machine and loaded in the same container.
Typical Applications
- Indoor and confined-space demolition
- Trenching for cables, water and drainage pipes
- Landscaping, garden and planting work
- Concrete breaking and road repair
- River, ditch and pond dredging
- Small earthworks and municipal projects
Factory Direct for Dealers and Rental Fleets
- Factory-direct pricing with volume tiers for dealers
- OEM / ODM: custom colors, private labeling and engine options. See our OEM & export services.
- Export packing: machines and attachments secured for ocean freight in 20GP / 40HQ containers
- Spare parts: wear parts and hydraulic components available for your service team
Request a Quote for the HT-13Q
Tell us your destination port, quantity, engine preference and attachments. Our export team will reply with factory-direct pricing, a container loading plan and the full technical datasheet.
